20% Single Phase IGBT Based Static Voltage Stabilizer With Precisions (VRP)

About 20% Single Phase IGBT Based Static Voltage Stabilizer With Precisions (VRP)

TSI-VRP assures seamless operation of electronicmachines by providing purest power through continuous pulse width modulation(PWM) switching of a buck-boost transformer using a convertor engine.

The high frequencyInsulated gate bi-polar transistor (IGBT) driven converter engine takes theincoming ac power, measures against the nominal voltage and adds or subtractsvoltage. 20,000 times per second, to achieve real-time compensation of voltagedisturbances, sag or swell. All this is achieved within 20 milliseconds throughseamless PWM compensation of voltage so that all voltage disturbances arecorrected within ITIC curve for flawless operation of electronics.

Key VRP Technology FeaturesAnd Consumer Benefits :

• Since the VRP technology controls any sag or swell cycle within 20 milliseconds ,it is the ideal voltage conditioner for your sensitive electronic devices.
• Since the VRP has in-built spike and noise controtit eliminates the need of additional spike & nose filters.
• Since the VRP does not switch components in the power path , it is compatible with most loads including regenerative loads.
• AC input circuit breakers prevent costly equipment damage due to load side faults.
• Automatic bypass circuitry assures fail safe operation.
• Light weight and compact size makes for ease of installation.
• Static technology results in quiet operation, high product up-time & low maintenance.
• High efficiency and energy savings though optimum voltage result in entry efficient operation.
• Tight control over electronic card failures. data corruption and machine breakdowns results in higher produttivity,lower operating costs and greater consumer comfort.

Applications :

• CNC & Robotics
• Auto & Auto Ancillary
• Oil & Gas
• Textile Spinning, Processing, Knitting, Weaving
• Engineering & Process Industry
• Wood Cutting
• Radar & Telecommunication
• R&D, Testing, Diagnostics
• Plastic Processing
• Printing & Packaging
• Building Management
• Security & Surveillance

Product Details :

• Standards & Safety : Designed to meet UL 60950-I standards, Protection class IP 20.
• Overload & Short Circuit Protection : Through Suitably rated input circuit breaker.
• Soft Switch On : This feature ensure that the output voltage is never higher than the input voltage upon switch on, before it commences full stabilization.
• Automatic Bypass : Regulator engine will be automatically bypassed when there is a fault condition.
• Surge Test Conditions : Per class 2 surge combination wave.
• Surge Let Through Voltages : 1.2x50us, 6kV , 8 x 20us , 3kA waveform , L-N <300V.

Note: Price range starts from 32169 to 77713 per piece.

Advanced Voltage Regulation

Utilizing IGBT-based technology, this static voltage stabilizer provides precise voltage control, making it highly reliable even during significant power fluctuations. The stabilizer guarantees consistent and clean power supply, which is critical for the optimal performance of sensitive machinery and equipment.


High Efficiency and Safety

Operating with an efficiency of over 96%, this stabilizer significantly reduces energy losses, contributing to lower electricity bills. It is designed with user safety in mind and incorporates robust protective features, ensuring trouble-free usage and extended equipment lifespan.


Flexible Installation & Warranty

With dimensions of 460 x 300 x 170 mm and weight ranging from 25 to 90 kg, the stabilizer can be installed in a variety of settings. The product warranty is valid within India for up to 24 months from the date of shipment or 21 months from installation, whichever is earlier, providing buyers added confidence and peace of mind.
